Brand Name : Sinuo
Model Number : SN441-1000L
Certification : Calibration Certificate (Cost Additional)
Place of Origin : China
MOQ : 1
Payment Terms : T/T
Supply Ability : 10 Sets Per Month
Delivery Time : 30 Days
Packaging Details : Export packing
Dust concentration : 2kg/m³
Metal mesh wire : 50um
Talc dosage : 2~5kgm³
Dust blowing method : Top-down
Coarse dust : Below 150um
Fine dust : Below 75um
Inner chamber size : 1000*1000*1000mm(W*D*H)
Outer chamber size : 1250*1450*2200 mm (W*D*H)
IP5X IP6X Dust Test Chamber Sand and Dust Testing Equipment for Electronics
Complied Standards & Clauses
The sand and dust test chamber is designed and manufactured according to IEC60529 Fig 2 IP5X and IP6X, IEC60598-1-2008, IEC60335-1 Clause 22.1 and etc.
Product Overview
The test chamber is specifically designed to evaluate the dust and sand resistance performance of sealed components and enclosures used in electrical and electronic devices, automotive and motorcycle parts, and various sealing systems. It simulates harsh dusty environments to assess how these products withstand use, storage, and transportation conditions under such exposure.
Featuring an intelligent, user-friendly PLC control system, the chamber ensures precise and efficient operation. The interior is crafted from premium SUS304 stainless steel for excellent durability and corrosion resistance, while the exterior is made of electrostatically sprayed A3 steel, ensuring a sleek and robust finish. A large observation window with a manual wiper allows clear visibility during testing. The device also incorporates comprehensive safety protection, delivering both reliability and peace of mind.
Technical Parameters
Device Name | Dust and Sand Test Chamber | ||
Main configuration | Cabinet | Enclosure material | A3 plate electrostatic spraying |
Inner material | SUS304B Stainless steel | ||
Lead hole | The sample can be external power supply through this hole | ||
Observation window | large observation window in the middle of the door | ||
Electrical control system | Controller | PLC Control: A. blowing dust time (stop, blowing) can be adjusted B. Cycle: arbitrary adjustable C. Preset test time: 0.1H-9999.9H arbitrary adjustable D. Power: On-off- On E. There are accumulating function and power-off protection function
| |
Vacuum system | Equipped with a vacuum pump, pressure gauge, air filter, pressure regulator, connecting pipe | ||
Security Protection Device | Power overload, short-circuit protection | ||
Ground Protection | |||
Voltage Protection | |||
Motor phase loss protection | |||
Alarm beep prompt | |||
Power Supply | Three phase 380V, 50Hz,3KW |
Details
![]() |
IP5X IP6X Dust Test Chamber Sand and Dust Testing Equipment for Electronics Images |
